Connecticut Airports Polygon is a 1:24,000-scale, feature-based layer that includes all airport features depicted on all of the U.S. Geological Survey (USGS) 7.5 minute topographic quadrangle maps that cover the State of Connecticut and are listed on the Federal Aviation Administration (FAA) "Airport Data (5010) & Contact Information" June 5, 2008 report. Airports that are listed by FAA and are visible on aerial photography (Connecticut 2004 Orthophotos and Connecticut 2006 NAIP Color Orthophotos from National Agriculture Imagery Program) are included. Airports that are listed by FAA but are not visible on aerial photography are not included. All airports listed by FAA are included in a separate point feature-based layer, Airport FAA CT. The airport point locations were generated from latitude and longitude coordinates contained in the FAA report and all the attribute information in the report was included. The airport layer is based partly on information from USGS topographic quadrangle maps published between 1969 and 1984 which does not represent airports in Connecticut at any one particular point in time. The layer does depict current conditions as to airports listed by FAA and having location identification codes and visible on aerial photography of 2004 and 2006. The layer delineates airports and heliports. It includes airport name, airport location code, type of facility, public or private use of facility and state the airport is located in. It does not include airport elevation, flight schedule, runway capacity, or ownership information. Features are polygonal and generally depict landing strips and perimeters for large and small airports and helicopter landing pads. Attribute information allows to cartographic representation (symbolize) and labeling of these features on a map. This layer was originally published in 1994 and slightly updated in 2005.
Connecticut Airports Polygon is 1:24,000-scale base map data. It depicts the location of airports listed by FAA in June, 2008 and visible on aerial photography. For base map purposes, use this layer with other 1:24,000-scale base map data such as Hydrography Master, Roads and Trails Master, Railroads Master, and Towns Master. Not intended for maps printed at map scales greater or more detailed than 1:24,000 scale (1 inch = 2,000 feet.). This layer is largely cartographic in nature and does not include specific information about individual airports.
In 2004, the State of Connecticut Department of Environmental Protection developed automated procedures to systematically maintain feature topology and attribute integrity for a set of related transportation data produced by the agency during the 1980's and 1980's from the 1:24,000-scale USGS DLGs. These layers include Roads and Trails Master, Roads and Trails, Railroads Master, Railroads, Buffered Roads Master, Buffered Roads, Airports Master, and Airports. Automated procedures were developed using ArcInfo Workstation 8.3 software and the Arc Macro Language (AML) as a scripting environment and recorded in an AML file named MAKECOVER.AML for the transportation category of data for the State of Connecticut, Department of Environmental Protection. For additional information related to the original source of data from the U.S. Geological Survey, refer to the Data User Guides and Standards for 1:24,000-Scale Digital Line Graphs and Quadrangle Maps available from the U.S. Geological Survey, National Mapping Program.
publication date
No restrictions or legal prerequisites for using the data. The data is suitable for use at appropriate scale, and is not intended for maps printed at scales greater or more detailed than 1:24,000 scale (1 inch = 2,000 feet). Although this data set has been used by the State of Connecticut, Department of Environmental Protection, no warranty, expressed or implied, is made by the State of Connecticut, Department of Environmental Protection as to the accuracy of the data and or related materials. The act of distribution shall not constitute any such warranty, and no responsibility is assumed by the State of Connecticut, Department of Environmental Protection in the use of these data or related materials. The user assumes the entire risk related to the use of these data. Once the data is distributed to the user, modifications made to the data by the user should be noted in the metadata. When printing this data on a map or using it in a software application, analysis, or report, please acknowledge the State of Connecticut, Department of Environmental Protection, the U.S. Geological Survey, National Mapping Program and the Federal Aviation Administration, Office of Aeronautical Information Services as the source for this information. For example, include the following data source description when printing this layer on a map: Airports - From the Airports Polygon layer, compiled and published by CT DEP, USGS and FAA. Source map scale is 1:24,000.
79 Elm Street
All attributes have valid values. Values are within defined domains. The basis for all attribute fields except State is the FAA report spreadsheet, NfdcFacility.xls, for Connecticut facilities. The attribute accuracy of the FAA data is not known. These values were manually entered.
Polygon features conform to the following topological rules. Polygons are single part. There are no duplicate polygons. Polygons do not self overlap. Polygons do not overlap other polygons. Polygons are bound by lines. Line features conform to the following topological rules. Lines are single part. There are no duplicate lines. Lines do not self overlap. Lines do not overlap other lines. Lines intersect only at nodes, and nodes anchor the ends of all lines. Lines do not overshoot or undershoot other lines they are supposed to meet and intersect. The tests of logical consistency were not performed.
The layer is incomplete in the sense that it does not include features for all FAA listed airports, heliports and seaplane bases. It is complete in the sense that it includes all FAA listed airports and heliports for which a representation can be located on aerial photography as of 2006. This data is not updated.
This portions of this data that came from the 1994 (2005 edition) airport layer comply with United States National Map Accuracy Standards for 1:24,000 scale maps. According to this standard, not more than 10 percent of the points tested are to be in error by more than 1/50 inch (40 feet) measured on the publication scale of a USGS 7.5 minute topographic quadrangle map. The remaining was screen digitized and the positional accuracy is unknown.
Airport features for all Connecticut quadrangle maps combined in a single, statewide layer. Airport_Master is in GeoDatabase Feature Class format.
A list of all FAA airport facilities in Connecticut and information about them such as facility name, facility identifier, type of facility, use of facility and latitude/longitude coordinates.
Geographically rectified, digital photography of the State of Connecticut suitable for use in a geographic information system as a visual source of features in the landscape. Used for digitizing airport features.
Geographically rectified, digital photography of the State of Connecticut suitable for use in a geographic information system as a visual source of features in the landscape. Used for digitizing airport features.
Updated airport polygon features for the State of Connecticut in GeoDatabase Feature Class format.
Updated airport point features for the State of Connecticut in GeoDatabase Feature Class format.
79 Elm Street
Internal feature number.
ESRI
Official facility name. (ex. Chicago O'Hare Intl)
Federal Aviation Administration
Feature geometry.
ESRI
ArcView Legend. Text field for symbolizing airport feature types on a map. Landing facility type. (ex. Airport, Balloonport, Seaplane Base, Gliderport, Heliport, Stolport, Ultralight)
State of Connecticut, Department of Environmental Protection and FAA
CT DEP
CT DEP
Location identifier unique 3-4 character alphanumeric identifier assigned to the landing facility. (ex. 'ORD' for Chicago O'Hare)
Federal Aviation Administration
State postal abbreviation
State of Connecticut, Department of Environmental Protection
Includes polygonal airport features such as airports and heliports published on the U.S. Geological Survey 7.5 minute topographic quadrangle maps, listed by Federal Aviation Administration and visible on aerial photography . Information encoded about features includes airport feature type classification, a standard symbology classification scheme, airport location code, airport name, airport use and state.
For additional information related to the original source of data from the U.S. Geological Survey, refer to the Data User Guides and Standards for 1:24,000-Scale Digital Line Graphs and Quadrangle Maps available from the U.S. Geological Survey, National Mapping Program. For additional information related to the FAA, refer to the "Airport Data (5010) & Contact Information" June 5, 2008 report or the Excel spreadsheet version, NfdcFacilities for CT. NFDC Airport Facilities Data Dictionary provides definition of the attributes in NfdcFacilities.
79 Elm Street
Although this data set has been used by the State of Connecticut, Department of Environmental Protection, no warranty, expressed or implied, is made by the State of Connecticut, Department of Environmental Protection as to the accuracy of the data and or related materials. The act of distribution shall not constitute any such warranty, and no responsibility is assumed by the State of Connecticut, Department of Environmental Protection in the use of these data or related materials. The user assumes the entire risk related to the use of these data. Once the data is distributed to the user, modifications made to the data by the user should be noted in the metadata.
The data distributor does not provide custom GIS analysis or mapping services. Data is available in a standard format and may be converted to other formats, projections, coordinate systems, or selected for specific geographic regions by the party receiving the data.
