Northeastern United States Index State Polygon includes generalized State boundaries for Northeastern United States. Includes data for Connecticut, Massachusetts, Maine, New Hampshire, New Jersey, New York, Rhode Island, and Vermont. The index version is a faster drawing representation of counties for use in interactive map applications. The data layer was created by merging towns within the same state. The source was Northeast United States Index Town Polygon which was, in turn, derived from Northeast United States Town Boundary Polygon. In the index version boundary lines have been minimally generalized to reduce vertices. Features such as small and medium offshore islands were eliminated. It may contain some boundary line and county name errors for states other than Connecticut.
publication date
Includes line features representing State boundaries; the shoreline; island shorelines; and lines enclosing open water areas along the outer limits of the data extent. (Source: State of Connecticut, Department of Environmental Protection)
Feature geometry. (Source: ESRI)
Land Class - Distinguishes land from water. This dataset includes a large water polygon feature that may impact polygon drawing performance. To improve drawing performance, exclude all water features by using the following expression in a layer definition query: LAND_CLASS = "Land"
| Value | Definition |
|---|---|
| Land | Land Feature - Mainland or island |
| Water | Water Feature - Marine and selected large fresh waterbody |
Connecticut Legend - Classifies features to highlight and differentiate Connecticut from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| Connecticut | State of Connecticut |
| Other States | Maine, Massachusetts, New Hampshire, New Jersey, New York, Rhode Island, Vermont |
| Water | Water |
Massachusetts Legend - Classifies features to highlight and differentiate Massachusetts from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| Massachusetts | Commonwealth of Massachusetts |
| Other States | Connecticut, Maine, New Hampshire, New Jersey, New York, Rhode Island, Vermont |
| Water | Water |
Maine Legend - Classifies features to highlight and differentiate Maine from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| Maine | State of Maine |
| Other States | Connecticut, Massachusetts, New Hampshire, New Jersey, New York, Rhode Island, Vermont |
| Water | Water |
New Hampshire Legend - Classifies features to highlight and differentiate New Hampshire from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| New Hampshire | State of New Hampshire |
| Other States | Connecticut, Maine, Massachusetts, New Jersey, New York, Rhode Island, Vermont |
| Water | Water |
New Jersey Legend - Classifies features to highlight and differentiate New Jersey from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| New Jersey | State of New Jersey |
| Other States | Connecticut, Maine, Massachusetts, New Hampshire, New York, Rhode Island, Vermont |
| Water | Water |
New York Legend - Classifies features to highlight and differentiate New York from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| New York | State of New York |
| Other States | Connecticut, Maine, Massachusetts, New Hampshire, New Jersey, Rhode Island, Vermont |
| Water | Water |
Rhode Island Legend - Classifies features to highlight and differentiate Rhode Island from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| Rhode Island | State of Rhode Island |
| Other States | Connecticut, Maine, Massachusetts, New Hampshire, New Jersey, New York, Vermont |
| Water | Water |
Vermont Legend - Classifies features to highlight and differentiate Vermont from other states. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| Vermont | State of Vermont |
| Other States | Connecticut, Maine, Massachusetts, New Hampshire, New Jersey, New York, Rhode Island |
| Water | Water |
State Code (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| 'blank' | No State designation. Used to encode open water features. |
| CT | State of Connecticut |
| ME | State of Maine |
| MA | Commonwealth of Massachusetts |
| NH | State of New Hampshire |
| NJ | State of New Jersey |
| NY | State of New York |
| RI | State of Rhode Island |
| VT | State of Vermont |
State Name (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| 'blank' | No State designation. Used to encode open water features. |
| Connecticut | State of Connecticut |
| Maine | State of Maine |
| Massachusetts | Commonwealth of Massachusetts |
| New Hampshire | State of New Hampshire |
| New Jersey | State of New Jersey |
| New York | State of New York |
| Rhode Island | State of Rhode Island |
| Vermont | State of Vermont |
Label Flag - Identifies polygons considered to be large and significant enough in size to be labeled on a map with county names. Polygons designated for labeling are assigned LABEL_FLAG values equal to "True", whereas small island polygons along coast, not typically labeled with county names, are assigned LABEL_FLAG values equal to "False". Label selected features with the MAP_LABEL attribute. (Source: State of Connecticut, Department of Environmental Protection)
| Value | Definition |
|---|---|
| True | Polygon feature you can label with MAP_LABEL attribute |
| False | Polygon feature not to label with MAP_LABEL attribute |
Map Label Text - Text values from the CNTY_NAME field used for map labeling purposes. Use the LABEL_FLAG field to query for polygon features to label with this field. (Source: State of Connecticut, Department of Environmental Protection)
Internal feature number. (Source: ESRI)
Connecticut Map Label - Map label text for Connecticut counties. Use this field to label all Connecticut counties without using the LABEL_FLAG field to query for the appropriate features to label, which is a slower technique. (Source: State of Connecticut, Department of Environmental Protection)
Not Connecticut Map Label - Map label text for all but Connecticut counties. Use this field to label all but Connecticut counties without using the LABEL_FLAG field to query for the appropriate features to label, which is a slower technique. (Source: State of Connecticut, Department of Environmental Protection)
Attributes identify and describe the geographic areas and boundaries between states and counties for the States of Connecticut, Massachusetts, New Hampshire, New Jersey, New York, Rhode Island, and Vermont. Use the BOUNDARY attribute to cartographically represent state and county boundary lines. Use the LAND_CLASS attribute to cartographically distinguish land from water polygon features. Use the STATE_COD, STATE_NAME, COUNTY_NAME or MAP_LABEL attributes to label polygon features with state and county names. Use the LABEL_FLAG attribute to identify polygons large enough to label with county names at larger scales using the MAP_LABEL attribute. Or use the CT_LABEL_Y and CT_LABEL_N attributes to label just Connecticut counties or all but Connecticut counties without querying for the appropriate features and labeling them with the MAP_LABEL values, which is a slower technique. Use the CT_LEGEND, MA_LEGEND, ME_LEGEND, and other similarly named polygon attributes to classify and highlight features in the corresponding state. This dataset includes a large water polygon feature that may impact polygon drawing performance. To improve drawing performance, exclude all water features by using the following expression in a layer definition query: LAND_CLASS = "Land"
79 Elm Street
Northeastern United States Index State Polygon data are intended for geographic display of states at statewide and regional levels. Use it to map and label states in an interactive map where drawing speed is important. Not suitable for analytic or similar GIS uses. This information should be displayed at scales appropriate for 1:100,000-scale data and smaller. The State of Connecticut, Department of Environmental Protection (CTDEP) assembled this regional data layer using data from other states in order to create a single, seamless representation of political boundaries within the vicinity of Connecticut that could be easily incorporated into mapping applications as background information.
All attributes have valid values. These attribute values are directly based on or derived from attribute and or spatial (feature location) information supplied by the respective data sources. This information does not depict official boundaries established by the respective state and municipal governments. It may contain some state and county boundary line errors for all states and county name errors for all states other than Connecticut.
The horizontal positional accuracy of this data is unkown.
This map layer includes boundaries for Connecticut, Massachusetts, Maine, New Hampshire, New Jersey, New York, Rhode Island, and Vermont. Data completeness has been altered from the original through elimination of features consistant with the goal of creating simplified, faster drawing data.
Polygon features conform to the following topological rules. Polygons are single part. There are no duplicate polygons. Polygons do not self overlap. Polygons do not overlap other polygons. Polygons are bound by lines. Line features conform to the following topological rules. Lines are single part. There are no duplicate lines. Lines do not self overlap. Lines do not overlap other lines. Lines intersect only at nodes, and nodes anchor the ends of all lines. Lines do not overshoot or undershoot other lines they are supposed to meet and intersect. The tests of logical consistency were not performed.
No restrictions or legal prerequisites for using the data. The data is suitable for use at appropriate scale, and is not intended for maps printed at scales greater or more detailed than 1:100,000 scale. Although this data set has been used by the State of Connecticut, Department of Environmental Protection, no warranty, expressed or implied, is made by the State of Connecticut, Department of Environmental Protection as to the accuracy of the data and or related materials. The act of distribution shall not constitute any such warranty, and no responsibility is assumed by the State of Connecticut, Department of Environmental Protection in the use of these data or related materials. The user assumes the entire risk related to the use of these data. Once the data is distributed to the user, modifications made to the data by the user should be noted in the metadata. When printing this data on a map or using it in a software application, analysis, or report, please acknowledge the State of Connecticut, Department of Environmental Protection as the data publisher. For example, include the following data source description when printing this layer on a map: Political Boundaries - From the Northeastern United States Index State Boundary layer, published by CT DEP.
79 Elm Street
Although this data set has been used by the State of Connecticut, Department of Environmental Protection, no warranty, expressed or implied, is made by the State of Connecticut, Department of Environmental Protection as to the accuracy of the data and or related materials. The act of distribution shall not constitute any such warranty, and no responsibility is assumed by the State of Connecticut, Department of Environmental Protection in the use of these data or related materials. The user assumes the entire risk related to the use of these data. Once the data is distributed to the user, modifications made to the data by the user should be noted in the metadata.
| Data format: | in format Shapefile, Feature Class (version ArcGIS) |
|---|---|
| Network links: | http://www.ct.gov/deep |
The data distributor does not provide custom GIS analysis or mapping services. Data is available in a standard format and may be converted to other formats, projections, coordinate systems, or selected for specific geographic regions by the party receiving the data.
